Coil Packing Line · Copper Coil Packing Line
Economy Copper Coil Packing Line
The Economy Copper Coil Packing Line automates coil handling and stacking for small and medium copper processors.
- 20 – 40 coils / hour (configuration dependent)
- Line capacity
- up to 30 000 kg (heavy-loading turnstile up to 60 t)
- Coil weight
- Ø 800 – 2 200 mm
- Coil outer diameter
- 15 – 450 mm (slit coil) / up to 2 000 mm
- Coil width
Overview
Economy Copper Coil Packing Line in short
The Economy Copper Coil Packing Line automates coil handling and stacking for small and medium copper processors. It takes the manual coil flipping and heavy lifting out of the packing bay and is built as a compact line for sites with limited floor space.
Turnstile (Component 2): Receives coils from the production line and provides precise orientation rotation.
Coil Downender (Component 3): Safely flips vertical coils to a horizontal position using hydraulic synchronization.
Coil Centering (Component 8): Uses laser positioning to ensure +/- 3mm accuracy before stacking.
Coil Stacking (Component 9): Automated stacking system, supporting up to 3 layers in various patterns.
Visual details
The Economy Copper Coil Packing Line machine
Main view, detail photos and a film of the machine in operation — see the wrapping station, the controls and how the coil is loaded and packed.
Watch it work
Economy Copper Coil Packing Line in operation
Video: FHOPE Automatic copper strip coil packaging line (YouTube). A film of this machine family — ask us for footage of the exact configuration, or for a live video call from the factory.
Technical data
Specifications
This is a project-engineered line, so there is no single catalogue table. The figures opposite are the platform data the line is built from; we issue the machine-by-machine specification with the quotation.
Get the technical proposal →| Line capacity | 20 – 40 coils / hour (configuration dependent) |
|---|---|
| Coil weight | up to 30 000 kg (heavy-loading turnstile up to 60 t) |
| Coil outer diameter | Ø 800 – 2 200 mm |
| Coil width | 15 – 450 mm (slit coil) / up to 2 000 mm |
| Stations | coil block station, roller station, wrapper, strapping, weighing, stacker |
| Strapping material | PET strap, steel strap |
| Control | Central PLC (Siemens / Rockwell / Mitsubishi) + HMI, ERP / MES interface optional |
| Safety | CE and ISO 13849 compliant: light curtains, interlocks, E-stops |
Platform specifications — this line is configured to order per project.
Machine features
What this machine does
- Fast ROI — Payback in 6-12 months through significant labour savings.
- Safety First — Eliminates dangerous manual coil flipping and heavy manual labour.
- Compact Design — Only 8m×5m footprint, easily fits into existing facilities.
- Easy Operation — User-friendly PLC control; operators can be trained in 1-2 days.
Typical applications
Where it is installed
- Steel service centres and rolling mills: slitting and shearing lines, cold roll and PPGI coils
- Copper and brass processing: coil slitting, vacuum handling and welding lines
- Wire industry: wire coil compacting, strapping and wrapping lines
- Pipe and profile plants: steel tube, plastic pipe and aluminium profile packing lines
Every machine is commissioned on site by FHOPE engineers, with operator training and a spare-parts list handed over at handover.
